Introduction
Diesel air compressors are used in a variety of manufacturing processes. In addition, most of these machines are portable, which means that you can move them to almost any location where you need them to be.
At Compresstech Resources, we take pride in offering portable diesel compressors in the Philippines. Our products mainly focus on industrial applications, supplying you with very high cubic feet per minute (CFM) and pounds per square inch (PSI). Their outputs can even reach up to 1,800CFM at 500PSI.
With more than 34 years of experience in the industry, our company has built a reputation for providing reliable and energy-efficient air systems, including diesel air compressors. Get in touch with us today for more information.
What Are Portable Diesel Compressors?
Portable air compressors are available in various styles, sizes, and designs, with their differences mainly caused by the airflow and pressure they produce. These machines are usually fueled by diesel. They also have various parts, including:
Compressor
The compressor for these machines is usually a rotary screw type, with most being oil injected and single stage. This part of the machine increases the pressure of the air and transports the substance through pipes.
Diesel compressors work just as how stationary electrical, rotary screw compressors would. However, a few minor differences would be within the control system.
Diesel Engine
A heavy-duty and reliable diesel engine is needed so that the machine can run for hours or weeks at a time. The diesel engine can either be directly coupled to the compressor element or connected with pulleys and a belt.
Like cars, engines use a motor to start up, so the portable compressor has a battery. Diesel engines also have safety devices for excessively low oil pressure and high temperatures.
Operation and Control System
Portable diesel compressors are easy to use since they usually have control buttons, indicator lights, or an hour counter. Control systems ensure that the engine’s speed is at an acceptable rate so that the compressor is in optimum condition. Most of the time, the control system is relatively simple and all pneumatic, with a minimum amount of electronics.
Additional Options
Aside from the three components, there are other accessories that portable air compressors may have. These include:
After Coolers – Cools down compressed air
Moisture Traps and Filters – Screens for dust, oil, water, or fumes depending on the compressed air quality needed
Different Tow Bar Designs – Connects your compressor to your car or truck
Heavy-Duty Compressor Inlet Filter – Protects the compressor from and dirt it might suck in (usually used in very dusty areas)
What Are the Different Types of Portable Diesel Air Compressors in the Philippines?
There are different kinds of portable air compressors available in the market. While these machines have the same technical functions, their main difference is the amount of output they produce. The three types of portable air compressors are:
Residential
These machines usually create less than 10 CFM or 90 PSI. As a result, residential air compressors are best suited for small, personal projects that need light air on a very irregular basis. These air compressors are also light enough to carry or pull by hand, making them easy to keep when they’re not in use.
Commercial
Best suited for applications using 60CFM to 250CFM at 150 PSI of compressed air, commercial-grade portable diesel compressors can be used daily. They are perfect for tire services, light construction, mobile mechanics, and other applications. Additionally, these 500- to 2,000- pound machines can be towed on their own chassis, skid mounted, or attached directly to a service vehicle.
Industrial
Used for highly specialized purposes, industrial diesel air compressors are large machines that can produce high levels of CFM and PSI. They are often used in construction sites where mobility is essential.
Portable compressors provide an alternative power source to start jackhammers, handheld screwdrivers, and other tools in case the main compressors are undergoing maintenance. They also usually come in tow-behind or utility-mounted models.
Rest easy knowing that Compresstech Resources’ products will last you for years, especially if you properly maintain them. We mainly offer industrial-grade portable diesel air compressors in the Philippines. Since industrial applications are so varied and unique, it is best to talk to a professional regarding which kind you may need the most. So reach out to us today to schedule a consultation with our team of experts.
What Are the Industrial Applications of Portable Diesel Compressors?
Air compressors power equipment through pressurized air, which has potential energy. It helps you operate automated valves, diverters, slide gates, dust collectors, instruments, and various other devices. By having a portable one in your facility, you can have one centralized compressor instead of a motor for each tool.
Portable diesel compressors in the Philippines have various applications. These include:
Manufacturing Plants
Having a portable diesel compressor is ideal for manufacturing sites that are spread over a large area. It is also perfect for businesses that have more than one location. You can easily take this machine wherever it is needed due to its mobility.
Backup Solutions
Main compressors are critical to your company’s production process. When your machine is undergoing maintenance, a portable diesel compressor comes in handy since it can function as an efficient backup solution. Now, you won’t have to pause any manufacturing activities and ensure that you’re on track when it comes to your deliverables.
What Should You Do Before Buying a Portable Diesel Compressor in the Philippines?
Before buying a portable diesel compressor, here are a few things you need to consider beforehand:
Determine the CFM Requirements You Need
To determine the total amount of CFM you need, simply add all the requirements of the tools you expect to use with the compressor unit simultaneously. It is also recommended that you add 30% to that number as a safety net.
Measure the PSI of Your Highest-Rated Tool
PSI measures the amount of pressure a compressor can produce. When selecting which portable diesel compressor is best suited for your needs, ensure that its PSI matches or is above your highest-rated tool. Most machines have a sticker attached to them that clearly indicates the PSI it needs to function properly. Additionally, you won’t have to add the measurements of your devices together, unlike with CFM.
Take Note of the Horsepower of the Unit
The CFM and PSI levels you need help in determining the amount of horsepower you will get. Manufacturers usually specify the running or rated horsepower of a unit, which is the output a compressor can produce once it reaches its operating revolutions per minute.
Aside from these, you should also note down the duty cycle and service factor of the compressor. The duty cycle describes whether the motor can run at full horsepower intermittently or constantly. If you require full power at all times, you need to get one that has a continuous duty cycle.
On the other hand, a motor’s service factor is the percentage of the rated horsepower that it can safely operate. Machines with higher service factors can run in extreme conditions, such as low voltage or high startup load, without experiencing many failures.
If you’re still unsure of what unit you should get, feel free to reach out to Compresstech Resources today. We have a team of experts who would be more than happy to go through the requirements of the machine you need. Afterward, we will suggest specific Airman portable diesel compressors in the Philippines that best fit your requirements and preferences.
Where Can You Buy a Portable Diesel Compressor in the Philippines?
Finding a reliable supplier of reliable and energy-efficient compressed air systems can be challenging. Fortunately, Compresstech Resources has got you covered. With more than 34 years of experience in the industry, we have partnered with various companies and provided them with top-quality lubrication equipment, fluid handling pumps, and air tools.
We also offer Airman portable diesel compressors in the Philippines, which are highly flexible and durable machines perfect for various applications. These include water well drilling, sandblasting and spraying, quarry and mining, and more.
Frequently Asked Questions
What Is the Average Lifespan of a Portable Compressor?
Portable diesel compressors are highly durable tools and are estimated to last for 10 to 15 years with regular maintenance and repair. It is vital that you properly care for your compressor to ensure that it lasts you as long as possible.
How Do You Maintain the Quality of Your Air Compressor?
The most common problems you may encounter with an air compressor can be easily resolved with the help of the user manual. Here are some of the maintenance tips you should follow to ensure the quality of your compressor:
Tighten the Nuts and Bolts – To Avoid Loose Screws and Fasteners That May Affect the Compressor’s Performance
Clean the Intake Valves – To Get Rid of the Dust Particles and Other Air-Bound Elements Sucked Into the Vents
Regularly Inspect the Hoses – To Ensure That They Have No Bends, Folds, or Holes
Change the Air Filters – To Maintain the Purity of the Compressed Air Generated
Drain Condensate From the Tanks – To Avoid Producing Air With a High Moisture Content
Change Out the Oil – To Allow Various Parts of the Engine To Function Smoothly With a Fresh Supply of Oil
Clean the Compressor Fuel Tank – To Clean Out Any Lingering Debris and Prevent the Fuel Particles From Becoming Toxic Waste
Inspect the Air Compressor Shutoff System – To Ensure That Your Compressor Can Deactivate Itself if Ever It Becomes Overheated
Change the Air or Oil Separator – To Avoid the Creation of Oily Mist
What Makes Industrial Air Compressors Different From the Other Units?
The main factor differentiating residential, commercial, and industrial air compressors would be their capacity to produce compressed air. Industrial units utilize rotary screws or centrifugal air to provide a very high CFM and PSI, reaching up to 1,800 CFM at 500 PSI. They also rely on higher horsepower motors and heavier-duty components.
An appropriately sized unit will deliver better performance with lower maintenance requirements. It will also ensure fewer chances of unexpected downtime that can affect your profit.
Conclusion
Having a portable diesel compressor at your facility is very beneficial as it can provide you with something to use when your standard units are undergoing maintenance. These machines get their name from their practical utility as well as their convenient and on-the-go size. Despite their smaller dimensions, they can produce just as much output as your regular air compressors. Furthermore, their portability makes them perfect for sites you need compressed air at different locations.
Make sure to do your research before purchasing any unit. Take note of the CFM and PSI you need and set a strict budget before spending your money on a new portable diesel compressor. Double-check the horsepower of the machine as well as it will affect its performance.
At Compresstech Resources, we understand that looking for a portable diesel compressor in the Philippines that perfectly matches the specs you need can be pretty tricky. Our team has the knowledge and expertise to provide you with a list of recommendations that would best meet your requirements. Rest easy knowing that we will closely listen to you during the consultation to ensure that we provide you with the best air compressor units available.
For more information about our products and services, feel free to get in touch with us today! We look forward to hearing from you.
